1.8 2.4 Microchip - 74HC595
Welcome to this exciting project! In this project, we will be using the 74HC595 chip to control a flowing display of 8
LEDs.
Imagine triggering this project and witnessing a mesmerizing flow of light, as if a sparkling rainbow is jumping between
the 8 LEDs. Each LED will light up one by one and quickly fade away, while the next LED continues to shine, creating
a gorgeous and dynamic effect.
By cleverly utilizing the 74HC595 chip, we can control the on and off states of multiple LEDs to achieve the flowing
effect. This chip has multiple output pins that can be connected in series to control the sequence of LED illumination.
Moreover, thanks to the chip’s expandability, we can easily add more LEDs to the flowing display, creating even more
spectacular effects.
Required Components
In this project, we need the following components.
It’s definitely convenient to buy a whole kit, here’s the link:
Name ITEMS IN THIS KIT LINK
ESP32 Starter Kit 320+
You can also buy them separately from the links below.
COMPONENT INTRODUCTION PURCHASE LINK
ESP32 WROOM 32E
ESP32 Camera Extension -
Breadboard
Jumper Wires
Resistor
LED
74HC595
Available Pins
Here is a list of available pins on the ESP32 board for this project.
Available Pins IO13, IO12, IO14, IO27, IO26, IO25, IO33, IO32, IO15, IO2, IO0, IO4, IO5, IO18, IO19,
IO21, IO22, IO23
Schematic
