SunFounder ESP32 Starter Kit
1.7 2.3 Colorful Light
In this project, we will delve into the fascinating world of additive color mixing using an RGB LED.
RGB LED combines three primary colors, namely Red, Green, and Blue, into a single package. These three LEDs
share a common cathode pin, while each anode pin controls the intensity of the corresponding color.
By varying the electrical signal intensity applied to each anode, we can create a wide range of colors. For example,
mixing high-intensity red and green light will result in yellow light, while combining blue and green light will produce
cyan.
Through this project, we will explore the principles of additive color mixing and unleash our creativity by manipulating
the RGB LED to display captivating and vibrant colors.
Required Components
In this project, we need the following components.
It’s definitely convenient to buy a whole kit, here’s the link:
Name ITEMS IN THIS KIT LINK
ESP32 Starter Kit 320+
You can also buy them separately from the links below.
COMPONENT INTRODUCTION PURCHASE LINK
ESP32 WROOM 32E
ESP32 Camera Extension -
Breadboard
Jumper Wires
Resistor
RGB LED
Available Pins
Here is a list of available pins on the ESP32 board for this project.
Available Pins IO13, IO12, IO14, IO27, IO26, IO25, IO33, IO32, IO15, IO2, IO0, IO4, IO5, IO18, IO19,
IO21, IO22, IO23
Schematic
26 Chapter 1. For Arduino User
