SunFounder ESP32 Starter Kit
5.19 Centrifugal Pump
The centrifugal pump converts rotational kinetic energy into hydrodynamic energy to transport fluid. The rotation
energy comes from the electric motor. The fluid enters the pump impeller along or near the rotating shaft, is accelerated
by the impeller, flows radially outward into the diffuser or volute chamber, and then flows out from there.
Common uses of centrifugal pumps include water, sewage, agricultural, petroleum, and petrochemical pumping.
• Centrifugal Pump - Wikipedia
Features
• Voltage Scope: DC 3 ~ 4.5V
• Operating Current: 120 ~ 180mA
• Power: 0.36 ~ 0.91W
• Max Water Head: 0.35 ~ 0.55M
• Max Flow Rate: 80 ~ 100 L/H
• Continuous Working Life: 100 hours
• Water Fing Grade: IP68
• Driving Mode: DC, Magnetic Driving
• Material: Engineering Plastic
• Outlet Outside Diameter: 7.8 mm
• Outlet Inside Diameter: 6.5 mm
5.19. Centrifugal Pump 733
