SunFounder ESP32 Starter Kit
The infrared receiver allows us to incorporate remote control functionality into our project, enabling us to interact with
and control devices using infrared signals.
Required Components
In this project, we need the following components.
Its definitely convenient to buy a whole kit, heres the link:
Name ITEMS IN THIS KIT LINK
ESP32 Starter Kit 320+
You can also buy them separately from the links below.
COMPONENT INTRODUCTION PURCHASE LINK
ESP32 WROOM 32E
ESP32 Camera Extension -
Breadboard
Jumper Wires
IR Receiver
Available Pins
Here is a list of available pins on the ESP32 board for this project.
Available Pins IO13, IO12, IO14, IO27, IO26, IO25, IO15, IO0, IO5, IO18, IO19, IO21, IO22,
IO23
Schematic
3.32. 5.14 IR Remote Control 403
