SunFounder ESP32 Starter Kit
4.11.1 Required Components
In this project, we need the following components.
It’s definitely convenient to buy a whole kit, here’s the link:
Name ITEMS IN THIS KIT LINK
ESP32 Starter Kit 320+
You can also buy them separately from the links below.
COMPONENT INTRODUCTION PURCHASE LINK
ESP32 WROOM 32E
ESP32 Camera Extension -
Breadboard
Jumper Wires
DHT11 Humiture Sensor
4.11.2 You Will Learn
• Get the temperature and humidity from the DHT11 module
• Serial Monitor for Upload Mode
• Add extension
4.11.3 Build the Circuit
The digital temperature and humidity sensor DHT11 is a composite sensor that contains a calibrated digital signal
output of temperature and humidity.
Now build the circuit according to the following diagram.
4.11. 2.8 Read Temperature and Humidity 521
