SunFounder ESP32 Starter Kit
When the temperature rises, the resistance of the thermistor decreases, causing the value read on I35 to decrease.
Additionally, by using a formula, you can convert the analog value into temperature and then print it out.
Wiring
Note:
The thermistor is black and marked 103.
The color ring of the 10K ohm resistor is red, black, black, red and brown.
Code
Note:
Open the 5.10_thermistor.ino file under the path of esp32-starter-kit-main\c\codes\5.
10_thermistor.
After selecting the board (ESP32 Dev Module) and the appropriate port, click the Upload button.
Always displaying “Unknown COMxx”?
After the code is successfully uploaded, the Serial Monitor will print out the Celsius and Fahrenheit temperatures.
How it works?
1.26. 5.10 Thermometer 93
