Sungrow SH3K6 - LCD Menu Structure

10 Appendix II: LCD Operation User Manual
80
Status
Description
Standby
The inverter waits for sufficient sunlight or battery level, then
the DC voltage recovers. The standby time can be set via the
iSolarCloud App or the iSolarCloud server.
Turn off
The inverter will stop running by manual “OFF” through the
LCD menu. Set to “ON” if you want to restart the inverter.
Startup
The inverter is initializing and synchronizing with the grid.
Upgrade
The DSP or LCD firmware is in its upgrading process.
Error
If an error occurs, the inverter will automatically stop operation,
trigger the AC relay and show “Error” on the LCD with the
indicator lit red.
Upd-fail
The master DSP program online upgrade failure.
If the inverter is in standby mode for more than 10 minutes, please
check:
 Whether the insolation is sufficient and the PV connection is correct.
 Whether the battery level is sufficient and the cable connection is
correct.
 If no anomaly is found, disconnect and connect the DC switch and
the main switch to restart.
 If it still does not work, contact SUNGROW.
10.2 LCD Menu Structure
Abbreviations
Abbreviation
Complete
Abbreviation
Complete
Csmp
Consumption
Exp
Export
Chrg
Charge
Tot
Total
Bat
Battery
Tmp
Temperature
SOC
State of Charge
SOH
State of Health
Vtg
Voltage
Curr
Current
Stt
State
Inv
Inverter
Pwr
Power
Frq
Frequency
Cap
Capacity
DRM
Demand respond mode
Ver.
Version
Ref.
Reference
CSTVtgChrg
Constant
charging voltage
MDCV
Max. discharging current
value
DChrg
Discharge
MCCV
Max. charging current
value
Prot.
Protection
Multi.
Multiple
