The setting range of the reactive power ratio is 0~100% or 0~-100%, corresponding to the
ranges of inductive and capacitive reactive power regulation respectively.
“Q(P)” Mode
The PF of the inverter output varies in response to the output power of the inverter.
table 8-3 “Q(P)” Mode Parameter Descriptions:
Parameter
Explanation
Default
Range
DE AU
Q(P) Curve
Select corresponding curve ac-
cording to local regulations
A
A, B, C
*
QP_P1
Output power at P1 on the Q(P)
mode curve (in percentage)
20% 25% 10% ~ 100%
QP_P2
Output power at P2 on the Q(P)
mode curve (in percentage)
50% 20% ~ 100%
QP_P3
Output power at P3 on the Q(P)
mode curve (in percentage)
100% 20% ~ 100%
QP_K1
Power factor at P1 on the Q(P)
mode curve
1
Curve A/C: 0.8 ~
1
Curve B: - 0.6 ~
0.6
QP_K2
Power factor at P2 on the Q(P)
mode curve
1
QP_K3
Power factor at P3 on the Q(P)
mode curve
0.95 0.90
QP_Enter-
Voltage
Voltage percentage for Q(P)
function activation
105% 100% ~ 110%
QP_
ExitVoltage
Voltage percentage for Q(P)
function deactivation
100% 90% ~ 100%
QP_
ExitPower
Power percentage for Q(P) func-
tion deactivation
20% 1% ~ 20%
QP_
EnableMode
Unconditional activation/deacti-
vation of Q(P) function
Yes Yes / No
* Curve C is reserved and consistent with Curve A currently.
