• Only when the engine is running and all of safety device are in function, the
parking brake can be released.
3) Temperature adjustment:Screw knob 3 to adjust temperature.
4) Wind speed adjustment Screw knob 4 to adjust wind speed.
5) Working Device Switch For security reasons there is a switch for blocking the
entire working cylinders that control the boom and the bucket. When it is pushed to
OFF position, the boom and bucket can’t be operated. Please push it to ON position
when you need to operate the boom or bucket. It is suitable for traveling a long
distance. When it is to travel a long distance, engage the switch.
6) Warning light switch This switch turns the warning light on and off. When press
the switch, the switch light flashes and the red light turns on; when press the switch
again, the red light turns off and the warning light stops flashing.
7) Working lights switch This switch is to activate the working lights.
8) Rear light switch (optional) This switch is to activate the rear lights.
9) Direction indicate button The direction indicate buttons are located on the both
joysticks. Press left button to engage the ldeft turning inicating light. Press right
button to engage the right turning indicating light.
10) Wiper switch This switch turns cabin wiper on and off. When press this switch,
wiper begin to work, green light comes on; press this switch again, green light goes
out, wiper stop work.
11) High flow switch This switch turns the high flow on and off. When turn on this switch
high flow begins to work ,When turn off this switch high flow stop work
12) Speed traveling switch
Press this switch,the machine is on high speed condition; press this switch again,
green light goes out, the machine is on low speed condition.
13) Cleaner switch This switch turns washing water on and off. When press this switch,
washing water begins to work, the light comes on; press this switch again, the light
goes out, washing water is turned off.
14) Horn button The button is placed on the joystick. Pressing it to activate the horn
for warn the persons around the machine.
15) Accumulator switch It is to cut off the battery supply circle. Switch off it when it
is necessary.
16) Warm hydrovalve Please close the hot water valve before using the refrigeration
system in summer or the aeration system in spring or autumn. In winter, please open
the hot water valve before using the heating system.
