SWL Series Skid Steer Loader
72
5.5.4.3 CHECKING THE FAN BELT
• Check the engine manual
5.5.4.4 CLEANING THE RADIATOR
• Use jet of compressed air or low-pressure water for
cleaning the radiator.
• If necessary use products available in the market
specially prepared for cleaning radiators.
• Never use oily products, since it facilitate the
adhesion of dust and reduces the efficiency of the
radiator.
5.5.4.5 CHECKING THE OIL LEVEL IN THE GEAR
CHAIN
• The checking has to be carried out in an level surface.
Proceed as follow to check the gear chain oil level:
1) Screw off the screw located in the bottom side on the chassis (See picture
below).
2) If the oil reaches the high of the hole, there is enough oil. If the oil is lower
than the hole, refill with the recommended type oil given in this manual.
5.5.4.6 CHANGING THE ENGINE OIL
• Proceed as follow to change the engine oil: refer to the ENGINE OPERATION AND
MAINTENANCE MANUAL before you doing change the engine oil.
1) Put a suitable container under the machine so that the oil can be drained
into it.
2) Remove the draining oil screw so that the oil flows into the container.
3) During the oil is flowing remove the engine refilling cap, in order easy
the flow.
4) Check and clean the engine oil drain plug treads and sealing surface,
install the drain plug.
5) Refill with the recommended engine oil given in this manual.
6) Fill the engine oil till the oil level to the H mark on the dipstick.
7) Close the refilling cap.
• Do not proceed to change the engine just after stopping the engine, since the oil is
still hot. Wait a while until the oil cool down.
• Oil is considered special waste. It has to be collected following the current
environment regulation.
5.5.4.7 CHANGING THE ENGINE OIL FILTER
Proceed as follow to change the engine oil filters:
1) Unscrew the filter head with a suitable tool.
2) Clean the filter support.
3) Lubricate the seal of the new filter.
4) Screw the filter. Turn it by hands for a half turn.
