SWL Series Skid Steer Loader
52
• Before start the engine put the manual accelerator to the idle position.
• For having a better efficiency, the speed must be proportional to the required
effort.
• There are two stoppers on the engine accelerator device to fix the limits of
minimal and maximal engine speed. The machine manufacturer or the engine
supplier fixed the stopper position after test Do modify the stopper position
without authorization. Unauthorized modification can cause engine over speed.
It can cause serious accident even death.
4.13 TRANSPORTING THE MACHINE ON OTHER VEHICLES
4.13.1 LOADING THE MACHINE
Always follow with the safety regulations when loading the machine on other vehicles. Any
neglect on the regulations may cause serious accidents.
Follow the following steps to load the machine to the
transporting vehicles:
1) Park the transporting vehicle on a firm
and level surface and apply the braking
system. Position wedges under the
wheel to secure the vehicle.
2) Lock the ramps on the vehicle. The
maximum ramp inclination is 15°. The
ramps must be parallel.
3) Move the machine on the ramps. Keep the empty bucket backwards and the
moving direction must be parallel with the ramps.
4) Move slowly the machine on the vehicle. Do not change the moving direction
on the ramps.
4.13.2 SECURING THE MACHINE
After move the machine on the transporting vehicle, to ensure the safety during transportation,
the steps following must be carried out to secure the machine.
1) Lower the bucket to the ground and let its back on the ground, see the figure
below.
2) Raise the safety bar, stop the engine and remove the key from the ignition
switch.
3) Put wedges under the wheels.
4) Use chain or cable to fix through the anchorage point.
