5.3.4 TORQUE FOR SCREWS
Unless other specification, tighten the nuts and bolts according to the torques shown in the
below table. Tighten the goods by the wrenches with gauge.
Thread Diameter (mm) Quality 8.8 Torque (Nm) Quality 10.9 Torque (Nm)
M 6 9~12 13~16
M 8 22~30 30~36
M 10 45~59 65~78
M 12 78~104 110~130
M 14
124~165
180~210
M 16 193~257 280~330
M 18 264~354 380~450
M 20 376~502 540~650
M 22 512~683 740~880
M 24 651~868 940~1120
M 27 952~1269 1400~1650
M 30 1293~1723 1700~2000
When tighten parts of the machine made by steel be careful to not tighten it too strong,
since you could damage this parts.
5.3.5 TOOL LIST
No.
Name
Qty.
1
INNER HEXAGON SPANNER S5 GB5356
1
2
DOUBLE-END SPANNER 8-10 GB4388
1
3
DOUBLE-END SPANNER 13-16 GB4388
1
4
DOUBLE-END SPANNER 17-19 GB4388
1
5
DOUBLE-END SPANNER 18-21 GB4388
1
6
DOUBLE-END SPANNER 30-32 GB4388
1
6 ADJUSTABLE WRENCH 300X36 1
8
CROSS POINT SCREWDRIVER WITH PLASTIC
HANDLE 6X150 GB1064-89
1
9
FLAT HEAD SCREWDRIVER WITH PLASTIC HANDLE
8X200
1
10
WIRE PLIERS 200 GB6259.1
1
11
GREASE GUN LH400CCH-18
1
12 ENGINE OIL FILTER SPANNER 1
13
TOOL BOX 385X180X155
1
14
BALL HAMMER 1.5P
1
15
CROSS POINT SCREWDRIVER 75X5
1
