SWL Series Skid Steer Loader
53
4.13.3 UNLOADING THE MACHINE
Always follow with the safety regulations when unloading the machine from the transporting
vehicles. Any neglect on the regulations may cause serious accidents.
Follow the following steps to unload the machine from the transporting vehicles:
1) Park the transporting vehicle on a firm and level surface and apply the
braking system. Position wedges under the wheel to secure the vehicle.
2) Lock the ramps on the vehicle. The maximum ramp inclination is 15°. The
ramps must be parallel.
3) Move the machine on the ramps. Keep the empty bucket forwards and the
moving direction must be parallel with the ramps.
4) Move slowly the machine from the vehicle. Do not change the moving
direction on the ramps.
4.14 LIFTING THE MACHINE
• Before lifting the machine, make sure nobody can approach the lifting area. While
lifting the machine, make sure nobody is under the machine and vicinal area.
• The operator must leave the machine before lifting.
• Only use homologated eyebolts and sufficient cables.
• Make sure the lifting equipment have enough capacity to lift the machine
• Eyebolts are not supplied by Sunward normally. The owner of the machine is
responsible for install the eyebolts on the cabin roof.
• The eyebolts must be installed properly on the four installing block on the roof of cabin.
1) Lower the bucket to the ground and fold
it completely.
2) Raise the restrain bar and stop the engine.
3) Fix the eyebolts to the installing blocks.
4) Insert the cables into the eyebolts and fix
them tighten.
5) Connect the cables to the upper lifting
ring.
6) Lift the machine slowly and keep the
machine balance during whole lifting
progress.
4.15 USE OF THE QUICK COUPLER
