SUNWARD SWL3210 - Left Joystick Controls

SWL Series Skid Steer Loader
35
3.6 JOYSTICKS
1) Left joystick The left joystick is for controlling the movements of the machine. It is
designed according to ISO 10968:2004. Its operating positions and relevant functions
2) are showed in the following diagram.
Direction
Function
Front
Forward
Back
Backward
Left
Turn left
Right
Turn right
Front & left
Forward left steering
Front & right
Forward right steering
