Appendix
Specifications
Product Specifications
System
Max Users 1000 (1:N), 10,000 (1:1)
Log Capacity 1,000,000
Image Log Capacity
5,000
CPU 1.1GHz DSP, 667MHz RISC
LCD 4.3” WVGA Touchscreen
Memory 4GB Flash + 512MB RAM
RF Options
13.56MHz Mifare/DESFire
Interfaces TCP/IP, RS485(2ch), RS232, USB, Wiegand, WiFi
Power 12VDC, PoE (Power over Ethernet)
General Dimensions
FaceStation
(W x H x D)
132 x 165 x 60 mm
Wall Bracket
(W x H)
97 x 107.8 mm (screw joint included)
Electric Specifications
Min. Avr.
Max.
Description
Power
Voltage(V)
10.8 12
13.2
Use certified power adapters
that meet the specifications.
Current Consumption
(mA)
-
- 850
Current Consumption
with USB Wireless LAN
(mA)
- - 1350
Switch
Input
VIH(V) 3.5 - 10.0
VIL(V)
-
- 2.0
Pullup Resistor
- 4.7K
-
Relay
Voltage
- -
24 VDC
Current
-
0.5 A 1.0 A
