suprema FaceStation - Optional Accessories

Getting Started
9
PIN 1 : Voice Signal (Red)
PIN 2 : GND (Blue)
PIN 3 : Power (Yellow)
PIN 4 : Video Signal (White)
PIN 5 : Door Open (Orange)
PIN 6 : GND (Black)
S2
S1
4
3
2
1
6 5 4 3 2 1
Optional Accessories
Power Adapter Secure I/O RF Card Plastic Stand
Mifare reader/writer Video phone
RF
Wireless Access Point
(For Wireless Models Only)
