CAMSHAFT + CYLINDER HEAD
Unit: mm (in)
ITEM STANDARD LIMIT
Cam height
IN.
35.48 – 35.53
(1.3968 – 1.3988)
35.18
(1.3850)
EX.
33.48 – 33.53
(1.3181 – 1.3201)
33.18
(1.3063)
Camshaft journal oil clearance
IN. & EX.
0.032 – 0.066
(0.0013 – 0.0026)
0.150
(0.0059)
Camshaft journal holder I.D.
IN. & EX.
22.012 – 22.025
(0.8666 – 0.8671)
----
Camshaft journal O.D.
IN. & EX.
21.959 – 21.980
(0.8645 – 0.8654)
----
Camshaft runout
IN. & EX. ----
0.10
(0.004)
Cam chain pin (at arrow “3”) 16th pin ----
Cylinder head distortion
----
0.05
(0.002)
