8A-7 Seat Belts:
Rear Seat Belt Removal and Installation
S5JB0A8106005
WARNING
!
Be sure to read “Precautions on Service and
Diagnosis of Seat Belt: ” before starting to
work and observe every precaution during
work.
Removal
1) Remove rear side sill scuff, rear side lower trim and
rear pillar trim referring to “Head Lining Removal and
Installation: in Section 9H”.
2) Remove rear seat belt referring to “Rear Seat Belt
Components: ”.
Installation
Reverse removal procedure for installation noting the
following.
• Seat belt anchor bolts should have an unified fine
thread (7/16-20 UNF). Under no circumstances
should any different sized or metric screw threads be
used.
Rear Seat Belt Inspection
S5JB0A8106006
WARNING
!
Be sure to read “Precautions on Service and
Diagnosis of Seat Belt: ” before starting to
work and observe every precaution during
work.
• Check the rear seat belt in the same way as “Front
Seat Belt Inspection: ”.
• As to seat belts with A-ELR, check them as follows.
– With vehicle at stop, pull seat belt all the way out,
let it retract a little and try to pull it. It should not be
pulled out, that is, it should be locked where
retracted.
– Let seat belt retract to its original state. Next, pull it
half way out, let it retract a little and try to pull it
again. It should be pulled out smoothly, that is it
should not be locked at this time.
Specifications
Tightening Torque Specifications
S5JB0A8107001
NOTE
The specified tightening torque is also described in the following.
“Front Seat Belt Components: ”
“Rear Seat Belt Components: ”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Fastener Information: in Section 0A”.
