1C-17 Engine Electrical Devices:
Specifications
Tightening Torque Specifications
S5JB0A1307001
Reference:
For the tightening torque of fastener not specified in this section, refer to “Fastener Information: in Section 0A”.
Fastening part
Tightening torque
Note
N⋅mkgf-mlb-ft
Accelerator pedal position (APP) sensor
assembly nut
6.0 0.6 4.5
)
APP sensor assembly bracket nut 6.0 0.6 4.3 )
ECT sensor 12.5 1.25 9.0 )
A/F sensor 45 4.5 32.5 )
Heated oxygen sensor 45 4.5 32.5 )
CMP sensor bolt 11 1.1 8.0 )
CKP sensor bolt 11 1.1 8.0 )
CKP sensor bolt 10 1.0 7.5 )
Knock sensor 22 2.2 16.0 )
MAF and IAT sensor screw 1.5 0.15 1.1 )
