Suzuki Grand Vitara 2005 Owner's Manual

Glass / Windows / Mirrors: 9E-22
Power Window Sub Switch Inspection
S5JB0A9506017
1) Remove front and/or rear door trim from door panel,
refer to Step 1) to 3) of “Front Door Glass Removal
and Installation: ” and/or “Rear Door Glass Removal
and Installation: ”.
2) Remove power window sub switch from door trim.
3) Check for continuity between terminals at each
switch condition.
If check result is not as specified, replace switch.
Door Mirror Components
S5JB0A9506018
I5JB0A950037-01
“1”
“3”
“2”
1
2,
2,
2,
I5JB0A950038-02
1. Door mirror
2. Door mirror mounting nut
:Tighten nuts in such order as indicated in the figure.
