ENGINE 3-11
• Remove the oil guide bearing retainer plate.
• Remove the spacer 1 and washer 2.
• Hold the generator rotor using the special tool.
• Remove the generator rotor nut.
' 09930-40113: Rotor holder
• Remove the generator rotor using the special tools.
' 09930-30104: Sliding shaft
09930-30161: Attachment “C”
• Remove the primary coil.
• Remove the crankcase securing screws.
