Figure 4-1
Front panel
Figure 4-2
Front panel LED detail
Table 4-1
Storage shelf front panel LEDs
RedAmberFlashing GreenSteady
Green
OffElementNumber
———NormalSystem offPower LED1
Malfunction
of both power
supplies
Malfunction
of one power
supply
—NormalSystem offGlobal enclosure
status LED
2
————Not used3
——Activity—No activityFirst I/O module LED7
——Activity—No activitySecond I/O module
LED
8
42About the Symantec Storage Shelf
About the storage shelf front panel
