5
Slide the drive carrier into the slot until it makes contact with the back of the
bay. Do not force the drive into place.
6
Close the front panel latch. The drive should click into place.
7
Replace the bezel.
See “Removing and replacing appliance hardware components” on page 100.
Removing and installing a NetBackup 5030 or
NetBackup 5230 power supply
NetBackup Appliances have two power supplies to ensure high availability operation.
If one power supply fails, you can replace it while the other supply provides power
to the appliance (hot-swap).
Caution: A power supply is only hot-swappable when two power supplies are
installed. At least one power supply must be in service to power the unit.
Note: The system periodically polls the power supplies to ensure that they operate.
When a power supply does not respond, an error message is posted on the hardware
monitor and an alert is sent to the designated party.
To remove a power supply
1
Put on a grounded ESD wrist strap or take other precautions against ESD
damage.
2
Check the LEDs for both power supplies in the unit. If one is green, you can
hot-swap the faulty power supply. If both are amber or one is amber and the
other is off, perform the shutdown procedure on the unit.
3
On the faulty power supply, unplug the power cord.
104Removing and replacing appliance hardware components
Removing and installing a NetBackup 5030 or NetBackup 5230 power supply
