Issue 2: Sep 99 TMSL 097-44018-26
Page 131
COMMAND CODE: RTRV-TH-MSG (Contd)
RESPONSE FORMAT (Contd)
EXAMPLE
Input:
RTRV-TH-MSG::DCIM-ALL:135;
Response:
SANJOSE-114 1997-12-08 15:04:13
M 135 COMPLD
"DCIM-1:100,,,"
"DCIM-2:80,,,"
;
This example, tagged as command 135, shows the persistence delay for the DCIM 1 card is 100 ms and
for the DCIM 2 card is 80 ms.
aid parameter value meaning
DCIM-a durmsg 0–2000 persistence delay: amount of time (ms) from an SSM change at an in-
put until the new SSM is sent to the MIS card (in 100 ms steps)
nswmsg (null) (not applicable)
swmsg (null) (not applicable)
hldovrmsg (null) (not applicable)
SHELF durmsg (null) (not applicable)
nswmsg 0–2000 nonswitching message delay: amount of time (ms) from a signal
quality SSM change (following the persistence delay and which does
not require a switch or rearrangement) at an input until the new SSM is
sent to the timing output cards (in 100 ms steps)
swmsg 0–2000 switching message delay: amount of time (ms) from a signal quality
SSM change (following the persistence delay and which requires a
switch or rearrangement) at an input until the new SSM is sent to the
timing output cards (in 100 ms steps)
hldovrmsg 0–3600 holdover message delay: amount of time (s) from when the clocks go
into holdover until the holdover SSM is sent to the timing output cards
(in 1 s steps)
