Symmetricom TimeProvider 500 series Reference Guide

TMSL 097-44018-26 Issue 2: Sep 99
Page 118
COMMAND CODE: RTRV-PORT
PURPOSE
RETRIEVE PORT
This command displays the framing, priority, reference type, signal type, and reference condition for a
port.
INPUT FORMAT
RTRV-PORT:[<tid>]:<aid>:<ctag>;
The parameter values in the table below are as follows:
a = 1–2 e = 1–11
b = 1–2 or ALL f = 1–12 (1–10 for TOTA-5 & TOTA-M)
c = 1–4 or ALL g = 1–10 (1–20 for EA20) or ALL
d = 2–4 (c > b) h = 2–10 (2–20 for EA20) (h > g)
RESPONSE FORMAT
<sid> <date> <time>
M <ctag> COMPLD
"<aid>:[<framing>],[<priority>],[<reference type>],
[<signal type>],[<reference condition>]" ...
;
Note: If the framing type has never been set for a port on an MRC or PSM card, the retrieved framing
type for that port will indicate AUTO. If this occurs, use the ENT-PORT command (if the port has not
been entered) or the ED-PORT command (if the port has been entered) to set the framing type for the
specified port.
aid meaning
DCIM-a-b specified port(s) on specified DCIM card
MRC-a-c[&&-d] specified port(s) on specified MRC card
PSM-e-c[&&-d] specified port(s) on specified PSM card
TO-f-g[&&-h] specified port(s) on specified timing output card
