Issue 2: Sep 99 TMSL 097-44018-26
Page 77
COMMAND CODE: RMV-PORT
PURPOSE
REMOVE PORT
This command removes a port from service, and places it into a maintenance state. When used on a tim-
ing output card, this command squelches the output of the removed port.
INPUT FORMAT
RMV-PORT:[<tid>]:<aid>:<ctag>;
The parameter values in the table below are as follows:
a = 1–2 e = 1–11
b = 1–2 or ALL f = 1–12 (1–10 for TOTA-5 &TOTA-M)
c = 1–4 or ALL g = 1–10 (1–20 for EA20) or ALL
d = 2–4 (c > b) h = 2–10 (2–20 for EA20) (h > g)
EXAMPLE
Input:
RMV-PORT::PSM-3-3:133;
Response:
SANJOSE-114 1997-12-08 15:04:13
M 133 COMPLD
;
This example, tagged as command 133, removes PSM-3, span 3 from service.
aid meaning
DCIM-a-b specified port on specified DCIM card
MRC-a-c[&&-d] specified port on specified MRC card
PSM-e-c[&&-d] specified port on specified PSM card
TO-f-g[&&-h] specified port on specified timing output card
