Symmetricom TimeProvider 500 series Reference Guide

Issue 2: Sep 99 TMSL 097-44018-26
Page 37
Table E. GTI Card Alarm Integration Times
INTEGRATION
PARAMETER
SETTING GTI CARD TYPE
ALARM INTEGRATION TIME
(SIGNAL DEFECT ONLY)
MINOR ALARM MAJOR ALARM
1 GTI -13 & -14 4 hours 24 hours
GTI -15, -16, -17, & -18 Rubidium ref: 4 hours Rubidium ref: 24 hours
Quartz ref: 3/4 hour Quartz ref: 6 hours
2 GTI -13 & -14 3 hours 18 hours
GTI -15, -16, -17, & -18 Rubidium ref: 8 hours Rubidium ref: 48 hours
Quartz ref: no minor alarm Quartz ref: 6 hours
3 GTI -13 & -14 1 hour 6 hours
GTI -15, -16, -17, & -18 Rubidium ref: no minor alarm Rubidium ref: 24 hours
Quartz ref: no minor alarm Quartz ref: 1 hour
4 GTI -13 & -14 10 minutes 1 hour
GTI -15, -16, -17, & -18 Rubidium ref: 1/2 hour Rubidium ref: 1 hour
Quartz ref: 1/2 hour Quartz ref: 1 hour
Notes:
1. The GTI types are as follows:
type
part #
GTI -13 090-42140-13
GTI -14 090-42140-14 & 090-44140-14
GTI -15 090-42140-15
GTI -16 090-42140-16 & 090-44140-16
GTI -17 090-42140-17
GTI -18 090-42140-18 & 090-44140-18
2. The times listed are from when a SIGNAL DEFECT occurs until a minor or major alarm is declared.
