Symmetricom TimeProvider 500 series Reference Guide

TMSL 097-44018-26 Issue 2: Sep 99
Page 162
TO-x
(x = 1–12)
CLOCK-x
(x = 1–2)
TIMING SIGNAL FROM CLOCK CARD
DISQUALIFIED
SC NSA
FAIL CARD FAIL:A/D FAILURE MJ SA
FAIL CARD FAIL:INTERNAL FAILURE MJ SA
FAIL CARD FAIL:REFERENCE VOLTAGE FAILURE MJ SA
FAIL CARD FAIL:PLL OUT OF LOCK MJ SA
INPUT-x
(x = 1–2)
TIMING SIGNAL FROM INPUT CARD
DISQUALIFIED
SC NSA
IS-NR-ACT IN-SERVICE NORMAL-ACTIVE SC NSA
IS-NR-STBY IN-SERVICE NORMAL-STANDBY SC NSA
MISMATCH CARD INFORMATION DOES NOT MATCH
DATABASE
SC SA
MISMATCH PROTECTION CARD CONFIGURATION MISMATCH
OR PAIRED CARD MISSING
SC NSA
OOS-MT OUT-OF-SERVICE MAINTENANCE SC NSA
OOS-MT-FLT OUT-OF-SERVICE MAINTENANCE-FAILED MJ/
MN
SA
QL-ALW OUTPUT TRANSMITTING AIS [OVERRIDE] SC NSA
QL-DNU NOT TO BE USED FOR SYNCHRONIZATION
[OVERRIDE]
SC NSA
QL-DUS NOT TO BE USED FOR SYNCHRONIZATION
[OVERRIDE]
SC NSA
QL-INH OUTPUT SQUELCHED [OVERRIDE] SC NSA
QL-PRC TRACEABLE TO PRC [OVERRIDE] SC NSA
QL-PRS TRACEABLE TO PRS/ST1 [OVERRIDE] SC NSA
QL-RES FORMAT SET BY USER [OVERRIDE] SC NSA
QL-SEC TRACEABLE TO SEC [OVERRIDE] SC NSA
QL-SMC TRACEABLE TO SMC [OVERRIDE] SC NSA
QL-SSUL TRACEABLE TO SSUL [OVERRIDE] SC NSA
QL-SSUT TRACEABLE TO SSUT [OVERRIDE] SC NSA
QL-ST2 TRACEABLE TO ST2 [OVERRIDE] SC NSA
QL-ST3 TRACEABLE TO ST3 [OVERRIDE] SC NSA
QL-ST3E TRACEABLE TO ST3E [OVERRIDE] SC NSA
Table F. Alarm/Event Summary (Contd)
<aid> <condtype> <conddescr> Severity
Service
Affecting
