2.3.3 Power connection
Power connectionPower connection
Power connection
You can power the unit directly using a DC supply or by using PoE (Power over
Ethernet).
CAUTION! Allow a period of 10 minutes before reapplying power if supplies
are switched between PoE and a DC supply of vice versa.
It is strongly recommended that if the reader is connected to an access
control unit it is also powered from this to prevent damage resulting from
any difference in earth potentials.
Using a DC power supply
Using a DC power supplyUsing a DC power supply
Using a DC power supply
To power the unit, connect red and black wires labelled Power to a power supply
rated at 10 to 14 VDC and capable of supplying a current of 500mA.
Label Wire Colour Signal Description
Power
Black 0V Power GND
Red +12V Power Input
Using PoE
Using PoEUsing PoE
Using PoE
Connect the DIGIgarde PLUS to a PoE-enabled network device such as an
Ethernet switch using the RJ45 connector and an appropriate CAT5 (or higher)
cable. You can also ‘inject’ power into the network cable using a midspan power
supply or PoE injector.
2.3.4
2.3.42.3.4
2.3.4 Wiegand
WiegandWiegand
Wiegand/Magnetic Clock Data to a compatible ACU
/Magnetic Clock Data to a compatible ACU/Magnetic Clock Data to a compatible ACU
/Magnetic Clock Data to a compatible ACU
Connect the wire WD0-OUT on the reader to Data 0 on the access control unit and
the wire WD1-OUT on the reader to Data 1 on the access control unit.
Label Wire Colour Signal Description
WG OUT
Yellow WD0-OUT Wiegand Output, Data 0
White WD1-OUT Wiegand Output, Data 1
Black GND Wiegand GND
Blue LED LED
