The operation of a door lock, the sensing of the door state and the triggering of an
alarm if the door is not in the expected position are set by the following five options
in the Advanced Options menu (see page 36):
Table 15 Lock and door sense settings
Setting Use
Lock Time that the lock drive is powered (0-254 seconds). Set to
zero to lock the door to all users.
Dsen.Delay Delay time (in seconds) after the lock is powered before the
DIGIgarde PLUS checks on the state of the door sensor. If
the door state at this time is anything other than that set in
Dsen Mode (see below) the alarm is triggered.
Dsen.Mode Normal state of door: none (no sensor connected), normally
open (NO) or normal close (NC). DIGIgarde PLUS checks
(after the DSen Delay – see above) that the door is restored
to its normal state after access has been granted to a verified
user.
Alarm Sound Whether the alarm is triggered if the door is not in its
expected position according to the Dsen.Mode setting.
Default setting is Off
AlarmSoundTime Set the time (seconds) of the door sensor alarm. Default
setting: 0.
Example:
Lock: 10s
Dsen Delay: 15s
Dsen Mode: NC
Alarm Sound: On
AlarmSoundTime: 15s
When a user is validated, the door lock is opened for
10s. If the door is not closed 15s after validation, the
unit triggers an alarm. The alarm sounds for 15s.
