Teac WX-7000 Instruction Manual

18
3.3. Status Dialog Display Area
If the data transfer speed is slow, the PC Remain field becomes dark yellow or red indicating that
the data transfer to the PC is delayed. In such a case, the memory in the WX main unit might
become full and the recording may finish earlier than indicated on the display.
REC button
VIEW button
Switch between the recording mode (REC) and the
view mode (VIEW).
Media
Indicate the media for recording (RDX, SD or PC) and
playback (RDX or SD).
Directory
Indicate the directory name for recording, and
indicate/select the directory for playback.
File
Indicate the file name for recording and
indicate/select the file for playback.
Comment
Show the comment which has been entered.
Channel
Number of channel being used in recording and
playback.
Sampling
Set and/or confirm the sampling frequency for
recording and playback.
Voice memo
Indicates ON/OFF of voice memo recording.
Start trigger
Show the start trigger currently set.
End trigger
Show the end trigger currently set.
Monitor output
Select and confirm the monitor channels.
WX Remain
Remaining recording time (hour: minute: second
and %( percentage)) on the specified device of the
WX main unit.
Background color is green when the remaining time is
more than 11%, and it is red when less than 10%.
PC Remain
Remaining recording time on the PC (hour: minute:
second).
Serial number
The name or serial number of the WX-7000 currently
connected to WX Navi software.
