20
3.5.
Menu Bar
3.5.1.
File Menu
New:
Select a recording device, o
r specify a file name.
Open:
Select a data to be
playback.
Copy:
Copy the files of the media
(RDX or SD) in the W
X-7000 recording unit to PC.
F
ormat:
F
ormat the media (R
DX or SD) in the WX-7000 recording unit.
Exit:
Exit this application.
3.5.2.
Setup Menu
System and channels:
System and each channel setting.
T
rigger:
T
rigger and inter
v
al recording settings.
Par
ameters Property:
Sav
e and load pa
rameters.
TEDS Property:
Read inf
ormation from the TEDS
sensor connected.
All Clear:
Initialize all system and cha
nnel settings.
20
22
