Teac WX-7000 Instruction Manual

56
8.5.2. Overlapping Waveforms
If you want to see waveform data overlapping channel 3 and 4, drag information area of channel
4 and move to channel 3 (red frame appears) and drop.
In case of overlapping waveform, [Quit Overlapping], [Waveform color] and [Channel select]
buttons appear on channel information area which shows channel number and channel name.
[Quit Overlapping] button works to quit overlapping and selected channel is displayed under
current position.
[Waveform color] button can change waveform color.
[Channel select] button can select showing waveform on top.
Channel Select
Waveform color
Selected channel
Quit overlapping
