Teac WX-7000 Instruction Manual

67
10.4. Synchronized recording
When recording in synchronization mode, please follow the step 1 to 5 described below.
Those setting changes must not be done on two PC’s at the same time. Please do it one by one.
Step 1 Switch from VIEW mode to REC mode.
If WX Navi is in VIEW mode (refer to section 3.2 Mode of WX Navi), please switch to REC mode.
You can ignore this step if WX Navi is already in REC mode.
First, press the REC button on the Slave unit to switch to REC mode, and then switch the Master
unit to REC mode.
Step 2 Setting recording media, sampling frequency and A/D converter on master
unit
The settings for recording media (RDX or SD), sampling frequency and A/D converter for the
Master unit are also applied to the Slave unit. Refer to section 16-1 Recording unit (WX-7000) in
the WX-7000 Owner’s Manual for recording bandwidth when you determine those settings.

Teac WX-7000 Specifications

General

Brand	Teac
Model	WX-7000
Category	Voice Recorder
Language	English
