9.2. Digital display
Click on the “Digital Display” in the tool bar to digitally display the instantaneous value of each
channel.
Up to 8 channels can be displayed simultaneously.
Values are converted and displayed according to the physical quantity conversion and unit set in
the System and Each Channel or Channel Property.
9.2.1. Channel Select drop-down list
Use this drop-down list to select the channel which you want to see.
9.2.2. Additional Window button
Click on this button to add digital display windows (up to 8 windows).
9.3. Digital 128ch display
This feature allows the operator to watch the instantaneous digital value of all channels
simultaneously. Click on the Digital Display (128ch) in the tool bar to activate this feature.
Channel Select
Additional Window
