27
5.2.2.
Upper Right Part
Clear Unit
All
unit
on
“Each
Channels
Settings
List
”
are
changed
back
t
o
de
fault
v
alue “V”
.
Clear Coeff
All
parameter
s
Coeff1
,
Coeff2
on
“Each
Channels
Settings
List”
are
changed back to de
fault v
alue “1.0”
.
Clear Offset
All parameters Off
set on “Each Channels Settings List
” are changed back
to default v
alue “0.0”
.
OK
All parameters are set
to WX
-7000 and close this d
ialog.
Cancel
Cancel to change and close
this dialog.
