6. TERMINAL FILE PROGRAMMING
EO3-11106
6.1 Instructions for Programming
6- 2
6.1 Instructions for Programming
On the MA-600 series adopting the LCD display, each programming operation is performed by selecting the
corresponding menu item on the LCD display.
The keyboard layout is automatically switched among three according to operation to be performed (ordinary
registration, read/reset, programming) when the Mode Lock is turned to the corresponding position.
Accordingly, in addition to the character code entry method, the character entries in programming operations are
also performed directly through the ordinary type keyboard.
6.1.1 SET Mode Menu
When performing a programming operation, a desired programming item is selected from the menu which is
shown on the LCD display. Programming menu tree is as shown below.
1 MESSAGES 4 RATE, LIMIT AMOUNT
1 COMMERCIAL MESSAGE 1 %- RATE (%-/%+)
2 FOOTER MESSAGE 2 VAT/TAX RATE
3 STORE MESSAGE 3 CUR EXCHANGE RATE
4 DISC AMT LIMIT
2 NAMES
1 DP KEY NAME
2 DP GROUP NAME 5 BASIC
3 CASHIER NAME 1 TIME
4 PLU (ITM NO.) NAME 2 DATE
5 SALESPERSON NAME 3 REGISTER NO.
6 FINANCIAL ITM NAME 4 HOURLY RANGE
7 PRINT ITEM NAME 5 KEY-IN TONE
8 DISPLAY ITEM NAME
9 ERROR ITEM NAME 6 OTHER
0 X/Z REPORT NAME 1 REPORT PRINT ITEM
2 SYSTEM OPTION
3 DP/PLU 3 KEY FUNCTION
1 DP 4 CASH KEY AMOUNT
1 DP SETTING 5 DRW WARNING TIME
2 UNIT PRICE 6 ROUND TBL 1 DIGIT
3 DIGIT LIMIT (PRICE) 7 ROUND TBL 2 DIGIT
4 KEY STICKER PRINT 8 RTC PRINT BUFFER
9 SERIAL NO.
2 PLU
1 PLU SETTING
2 UNIT PRICE
3 ASSIGN TO KEYBOARD
4 DELETE (INDIV)
5 DELETE (ALL)
To Next Page
