12. Loosen the belt and remove it.
13. Remove the rear pulley.
For details, refer to the disassembly procedure described in the chapter:
$7.21 DISASSEMBLING THE REAR PULLEY
ATTENTION: During reassembly the ange bearing screws on the rollers, apply Loctite
243 on the screw thread.
Tighten the screws with a torque of 22 Nm (16.2 lbf-ft). Apply this procedure to all four
screws.
TECHNOGYM RUN Technical Service Guide
Rev. 1.0
- 61 -TSG-00284-EN- Uncontrolled copy if printed
