Technogym Forma - Disassembling the Handlebars

FORMA: Service & Maintenance manual - rev. 3.0
Page 7.26
7.22. DISASSEMBLING THE HANDLEBARS
Figure 7.22-1
1. Turn off the machine and unplug the mains
lead from the wall outlet.
For each handlebar, and on both the parts
secured to the machine column:
2. Shift the rubber bushings a.
3. Back off the 2 dowels b using a 3-mm hex T
wrench.
4. Remove the HANDLEBAR
To reassemble the HANDLEBARS, carry out the
above steps in reverse order.
