FORMA: Service & Maintenance manual - rev. 3.0
Page 7.14
7.11. DISASSEMBLING THE SHOCK ABSORBERS
Figure 7.11-1
Carry out the procedures described in paragraph
7.10. “Disassembling the tread-belt and running
track”.
1. On each side of the machine, remove the
SHOCK ABSORBERS from the top,
detaching them from the adhesive film.
To reassemble the SHOCK ABSORBERS, carry
out the above steps in reverse order.
