FORMA: Service & Maintenance manual - rev. 3.0
Page 2.4
• Portable connectors
name type of connector connection
CN28 MOLEX mini-fit 7x2 m. portable to CPU board (actuator drive)
CN29 MOLEX mini-fit 7x2 f. portable to driver board (actuator drive)
CN39 Terminal block to filter, power supply, inverter and selector
CN46 MOLEX mini-fit 3x2 f. portable to up-down motor
2.5.3. W
IRING
FR-1/A: Power supply cable
Power inlet socket – Filter - Fan interface board
Power inlet
socket
Signal Color Filter Fan
interface
board
PE
Black Fast on - -
Fast on Live
Black - Fast on -
Blue Fast on - -
Fast on Neutral
Blue - Fast on -
Fast on - -
-
Earth
Yellow-green
Yellow-green
Fast on -
Eyelet
This cable incorporates a 348 Ohm, 100 Mhz ferrite with coil on the live and neutral conductors.
FR-2: High voltage power supply cable
Filter – High voltage distribution terminal block
Filter Signal Color Terminal block
CN39
Fast on Live Black L
Fast on Neutral Blue N
Fast on Earth Yellow PE
FR-3/L: Power supply high voltage input cable
High voltage distribution terminal block – Power supply
Terminal block
CN39
Signal Color Power supply
CN1
N Neutral Blue 4
L Live Black 6
FR-4: Inverter high voltage input cable
High voltage distribution terminal block – Inverter
Terminal block
CN39
Signal Color Inverter
N Neutral Blue N
L Live Black L1
