9.5.1. M
ONITOR FUNCTION PARAMETERS
Parameter Description
d01 Motor output frequency
d02 Motor current draw
d04 Direction of movement
d05 Status monitor of intelligent terminal input signals
d06 Status monitor of intelligent terminal output signals
d07 “Converted” motor output frequency
d08 Monitor of last alarm condition
d09 List of the last error conditions
9.5.2. M
ODIFIED PARAMETER SETTINGS
The following table shows the parameters which must be configured with a different value from the
inverter defaults:
Value Parameter Description
Forma 3 Forma 2
A04 Maximum frequency setting 80 100
A61 Maximum frequency limit 80 80
A62 Minimum frequency limit 4.6 4.6
A81 Selection of AVR function 00 00
A82 Selection of voltage of AVR function for the motor 240 240
b12 Level of electronic thermal setting 6.00 6.00
b22 Level of overload restriction setting 12.00 12.00
b83 Carrier frequency setting (KHz) 16.0 16.0
b90 Dynamic braking usage ratio 20 20
C03 Function of terminal 3 setting 12 12
C13 Condition of terminal 3 setting 01 01
C41 Level of overload signal setting 5.00 5.00
C81 Analog meter adjustment O 99 99
C82 Analog meter adjustment OI 75 75
H02 Motor data selection 01 01
H03 Motor capacity setting 1.1 1.1
H05 Motor constant K
p
setting 99 99
H20 Motor constant R1 setting 2.984 2.984
H21 Motor constant R2 setting 1.598 1.598
H22 Motor constant L setting 18.16 18.16
H23 Motor constant Io setting 2.61 2.61
H24 Motor constant J setting 20 20
H30 Motor constant R1 (Autotuning data) 2.984 2.984
H31 Motor constant R2 (Autotuning data) 1.598 1.598
H32 Motor constant L (Autotuning data) 18.16 18.16
H33 Motor constant Io (Autotuning data) 2.31 2.31
H34 Motor constant J (Autotuning data) 20 20
