FORMA: Service & Maintenance manual - rev. 3.0
Page 2.3
2.5.2. C
ONNECTORS
• CPU board
name type of connector connection
K1 AMP MODU I 4x1 pin f. to driver board (low voltage input)
K2 AMP MODU I 2x1 pin f. to LED board (low voltage output)
K4 AMP MODU II 9x2 pin f. to driver board (actuator drives)
K6 AMP MODU II 4x1 pin f. to serial connector for TGS
K12 Flat 5x2 pin f. to LED board (LED driver output)
K14 AMP MODU II 4x1 pin f. to cardio receiver
EM AMP MODU II 2x1 pin f. to emergency button
• LED board
name type of connector connection
K2 AMP MODU I 2x1 pin f. to CPU board (low voltage input)
K12 Flat 5x2 pin f. to CPU board (LED driver input)
• Driver board
name type of connector connection
J1 AMP MATE-N-LOCK 3x2 pin f. to up-down motor
J2 2 pin terminal block to transformer (low voltage ac input)
J3 AMP MODU I 4x1 pin f. to power supply (low voltage input)
J4 AMP MODU I 4x1 pin f. to CPU (low voltage output)
J5 AMP MODU II 6x1 pin f. to inverter (inverter drive)
J6 AMP MODU II 9x2 pin f. to CPU board (actuator drive)
• Power supply
name type of connector connection
CN1 PANDUIT 6 pin m. to filter (mains voltage input)
CN2 PANDUIT 6 pin m. to driver board (low voltage output)
• Fan interface board
name type of connector connection
CN1 AMP MODU I 2x1 pin f. to inverter
CN2 4-pin terminal block IN: from power inlet block (mains voltage
input)
OUT: to fan (mains voltage output with
isolating relay on the circuit board)
