FORMA: Service & Maintenance manual - rev. 3.0
Page 7.13
To reassemble the TREAD-BELT and the
RUNNING TRACK, carry out the above steps in
reverse order.
When reassembling the TREAD-BELT,
make sure that:
• it is assembled in the direction
indicated by the direction arrow on
the inner side, if one is present;
• it is correctly centered on the
RUNNING TRACK;
• it is not pinched by the RUNNING
TRACK.
Lubricate the RUNNING TRACK
before reassembling it.
To facilitate reassembly of the
RUNNING TRACK on the frame, push
it against the vibration damper so that
the upper pad does not obstruct its
movement.
After completing the procedure, adjust
the tension and centering of the belt as
described in paragraphs 8.2. and 8.3.
and adjust the tension and alignment of
the motor drive-belt as described in
paragraph 8.4. .
