FORMA: Service & Maintenance manual - rev. 3.0
Page 2.8
FR-15: Up-down motor cable extension
Portable connector – Driver board
Portable
CN46
Signal Color Driver board
J1
1 Motor + White 1
2 Motor - Blue 2
5 Up-down motor pulses Red 5
6 Pulse Gnd Black 6
FR-16: Fan power supply cable
Fan interface board – Fan
Fan interface
board
Signal Color Fan
OUT Live Black Fast on
OUT Neutral Blue Fast on
FR-17: Fan driving cable
Fan interface board – Inverter
Fan interface
board
Signal Color Inverter
1 Fan enable Black L
2 Gnd Red CM2
RL-14: Heart rate meter cable
CPU board – Heart rate receiver
CPU board
K14
Signal Color Receiver
1 +5 Vdc Red 1
2 Pulse per beat Blue 2
3 Gnd Black 3
RL-17: Emergency cable
CPU board – Emergency button
CPU board
EM
Signal Color Emergency
button
1 Gnd White Already connected
2 Signal Black Already connected
