FORMA: Service & Maintenance manual - rev. 3.0
Page 2.11
FR-7: Inverter cable
Driver board – Inverter
Driver board
J5
Signal Color Inverter CN43
- Thermal cutout Green 3 2
1 White -
-
Thermal cutout Gnd
White P24
1
2 Start Grey 1 -
3 Alarm Red AL0 -
4 Alarm Gnd Purple AL1 -
5 Speed Brown O -
6 Speed Gnd Black L -
