0WCU0943xx: Low Kit Board / UI Cable
Low Kit Board Signal Colour Fly connection “C”
1 Power Supply +5Vdc Brown 1
- n.c. - -
- n.c. - -
4 RPM SQW Yellow 6
5 Power Supply GND White 5
- n.c. - -
7 Direct RPM+ Green 4
- n.c. - -
Table 9
0WCU0941xx: NFC / UI Cable
NFC Board Signal Colour Fly connection “B”
1 Power Supply +5V Brown 1
2 rs232/NFC_TX Yellow 2
3 rs232/NFC_RX Green 3
-
-
-
-
8 GND White 4
Table 10
0WCU0942xx: Knob sensor / UI Cable
Angle Sensor Board Signal Colour Fly connection “A”
1 Power Supply +3.3V Brown 1
2 GND White 2
3 Analog Signal Green 3
- - - -
- - - -
Table 11
