Technogym SKILLROW - The Display Doesnt Remain Switched on at High Resistances or During POWER Workouts

[1]: The calibration of the equipment is described at the paragraph “6.7.1 equipment calibration”.
The reference values of equipment calibration are the following: Level 1: 5299; Level 10: 2695;
Level 11: 2322: Level 12: 1921; Level 13: 1446. This is only an indication about the order of ma-
gnitude of values. The values should decrease, with the increasing of the levels. If the values are
wrong, the cable that connects the angle sensor board to the CPU mainboard or the angle sensor
board could be broken.
6.6.6 THE DISPLAY DOESN’T REMAIN SWITCHED ON AT HIGH RESISTANCES OR
DURING POWER WORKOUTS
The display doesn’t remain
switched on at high resistances
or during POWER workouts.
Charge the battery for 10 hours with the
external power supply [1]. Problem
solved?
OK. Problem solved.
Verify the integrity of :
- the jack and
- the cable that connects the jack,
generator and low-kit board.
If they are functioning, replace the
battery. Charge the new battery for 10
hours with the external power supply.
Yes
No
Figure 33
[1]: You must use the external power supply with the following characteristics: 24 Vdc 0.5A jack
5.5x2.1
.
SKILLROW:
Technical Service Guide - Rev. 1.1
Page 65e-mail: support@technogym.com
