Technogym SKILLROW - Structure For Entering Commands

SELECT THE COM PORT
SELECT DTR
SELECT +CR
RESCAN
SET THE BAUD RATE 19200
COMMANDS SECTION
Figure 20
6.2 STRUCTURE FOR ENTERING COMMANDS
The structure of the command/message is: @COMANDO [ARG1] [ARG2]#
Character Required Description
@ YES Message start marker.
COMMAND YES
Command. The acceptable commands are described in the
following sections.
ARG1 NO First Topic of the command (if required by the command).
ARG2 NO Second Topic of the command (if required by the command).
#
(hash)
YES Message end marker.
Table 12
SKILLROW:
Technical Service Guide - Rev. 1.1
Page 40
e-mail: support@technogym.com
