3.2.5 LOW KIT BOARD
Figure 11: left side of the equipment
The low kit board works only when the user starts rowing.
The low kit board is powered by the generator.
The low kit board powers the console U-I.
The low kit board is a charging circuit for the lead baery.
The low kit board has 2 LEDs:
-the rst LED is always xed green. This indicates that the board correctly distributes the output
voltage.
- the second LED ashes:
- If the LED ashes green: the baery is recharging.
- If the LED ashes orange: the baery is discharging.
The low kit contains a fuse, in the F3 position of the board. Follow the below procedure to check it:
a. Use a multimeter set to measure the continuity;
b. Place the tips of the multimeter against the two metal ends of the fuse (F3) (parallelepiped vo-
lume);
c. If there’s continuity, the fuse is OK.
